The resistance welding machine series includes a MFDC projection welder, stationary spot welder, seam welding machine and other resistance welding equipment.

MFDC Resistance Welding Machine

2. 55KVA-440KVA Stationary Spot Welder, Projection Welder Low configuration MFDC resistance welding machines are primarily used for spot welding and projection welding processes, such as the welding of carbon steel, stainless steel, aluminum, copper and other alloys.
2. 220KVA-880KVA Stationary Spot Welder, Projection Welder The resistance welding machine power ranges from 220KVA to 880KVA.
  The maximum short circuit current from 40KA to 110KA.
  At an air pressure of 6bar, the welding pressure of our welder ranges between 10000~24000N.
2. 25KVA-220KVA Stationary Spot Welder, Projection Welder The resistance welding machine power ranges between 25KVA to 220KVA.
  The maximum short circuit current of our welding machine ranges between 15.5KA to 40KA.
  At an air pressure of 6bar, the welding pressure of our welder reaches up to a range of 480~15000N.
2. 200KVA MFDC Circular Seam Welder The 200 kVA MFDC circular seam welder is equipped with Heron’s HRC-802 medium-frequency inverter controller and HRC medium-frequency welding transformer. Its patented silver-shunt electrode holder design supports stable current transmission, improved reliability, and long-term durability.
2. 200KVA MFDC Longitudinal Seam Welder The 200 kVA MFDC longitudinal seam welder is designed for cylindrical workpieces and longitudinal seam welding applications. Its rigid structure, stable clamping system, and MFDC inverter technology support consistent seam quality in continuous production.

Capacitor Discharge Resistance Welding Machine

2. 10KJ-120KJ Capacitor Discharge Resistance Welding Machine (Spot Welder, Projection Welder) The power of our resistance welding machine is ranging from 10KJ to 120KJ.
  The maximum short circuit current of our welding machine is ranging from 90KA to 1000KA.
  At air pressure of 6bar, the welding pressure of our welder is ranging from 15KN to 240KN.
2. 500J-8000J Capacitor Discharge Resistance Spot Welding and Projection Welding Machine The power of our resistance welding machine is ranging from 500J to 8000J.
  The maximum short circuit current of our welding machine is ranging from 14KA to 80KA.
  At air pressure of 6bar, the welding pressure of our welder is ranging from 1240N to 15000N.
2. Capacitor Discharge Resistance Seam Welding Machine The resistance welding machine power is 500J.
  The maximum short circuit current of our welding machine is 14.6A.
  At an air pressure of 6bar, the welding pressure of our welder is 240N.
  The effective throat depth is 116.5mm.

AC Resistance Welding Machine

2. 25KVA-150KVA AC Resistance Welding Machine (Spot Welder, Projection Welder) The power of our resistance welding machine is ranging from 25KVA to 150KVA.
  The maximum short circuit current of our welding machine is ranging from 12KA to 34KA.
  At air pressure of 6bar, the welding pressure of our welder is ranging from 2510N to 15000N.
2. 50KVA-500KVA AC Resistance Welding Machine (Spot Welder, Projection Welder) The power of our resistance welding machine is ranging from 50KVA to 500KVA.
  The maximum short circuit current of our welding machine is ranging from 12KA to 76KA.
  At air pressure of 6bar, the welding pressure of our welder is ranging from 2510N to 24000N.
2. 50KVA-200KVA AC Circular Seam Welder The seam welder is designed for circular seam welding of cylindrical components. Its AC resistance welding system supports stable seam formation for applications requiring continuous, reliable welds.
2. 50KVA-150KVA AC Longitudinal Seam Welder This resistance welding machine is designed for cylindrical workpieces and longitudinal seam welding applications. Its rigid frame, stable clamping system, and AC resistance welding technology help deliver consistent seam welding performance.

Three Phase DC Resistance Welding Machine

2. Three phase DC resistance welding machine (spot welder, projection welder)
  Three phase DC resistance welding machines are primarily used for spot welding and projecting welding processes on ferrous metal.

Heron is engaged in making resistance welding system, is an experienced resistance welding machinery manufacturer and welding solution provider. Since 1997 we have been offering wide range of MFDC resistance spot welders, capacitor discharge resistance seam welders, MFDC resistance projection welding machines and robotic welding system for global customers.
